Three phase ac motors 40mm Series Mini Servo Motor 220V 50W 0.16N.M 3000rpm High Speed Ac Servo Motor

Product Categories

CHANGZHOU JKONGMOTOR CO.,LTD

Contact Now

Three phase ac motors 40mm Series Mini Servo Motor 220V 50W 0.16N.M 3000rpm High Speed Ac Servo Motor

Name: Three phase ac motors 40mm Series Mini Servo Motor 220V 50W 016NM 3000rpm High Speed Ac Servo Motor
Brand: Jkongmotor
Price: 1 USD

Wholesale Three phase ac motors 40mm Series Mini Servo Motor 220V 50W 0.16N.M 3000rpm High Speed Ac Servo Motor from china suppliers

Brand Name : Jkongmotor

Model Number : 40ST-M00130

Certification : CE, ROHS,ISO9001

Place of Origin : Jiangsu, China (Mainland)

Price : US $220.00 - US$248.00

Packaging Details : with export carton . big quantity with pallet

Delivery Time : For samples , 7-15 days / For batch , 15-25days

Payment Terms : T/T , paypal , Western Union, L/C

MOQ : 3-10pcs

Supply Ability : 10000 pcs/month

Type : Servo Motor

Output Power : 50W

Speed : 3000rpm

Voltage : 220v

Color : black

Rated torque : 0.16NM

Contact Now

40mm Series Mini Ac Servo Motor & Driver 220V 50W 0.16N.m 3000rpm high speed AC servo motor

Item	Model No.	Holding torque	Rated speed	Rated current	Rated power	Driver
Item	Model No.	Nm	rpm	A	KW	Driver
1	40ST-M00130	0.16	3000	0.4	0.05	JK-G2A3204
2	40ST-M00330	0.32	3000	0.6	0.1	JK-G2A3204
3	60ST-M00630	0.637	3000	1.5	0.2	JK-G2A3204
4	60ST-M01330	1.3	3000	2.8	0.4	JK-G2A3204
5	60ST-M01930	1.9	3000	3.5	0.6	JK-G2A3208

Product feature of 3 phase ac motor:

1. Capacity range: 0.1kW~3kW

2 . Input voltage: AC 200V~230V,single-phase/three-phase or three-phase input.

3 . Location /Speed/Torque control mode.

4 . Encode resolution is 17 bit(160000 ppr).

5. High speed pulse input (4MPPS).

6 .Support Modbus communication protocol(communication port: RS-485 / RS-422 / RS-232)

7. The realization of high precision positioning control:

1) ASDA-B2 series support 17bit (160000 ppr) high resolution encode, satisfy the need of machine and equipment’s high resolution location control and Smooth running at low speed.

2) With three sets of automatic resonance suppression filter, effectively restrain the vibration of agency action, so it run more smoothly and more complete.

8. Simple operation, saving cost:

1) Power cable and encode cable shared with the ASDA-B series, and match the ECMA series motor with the same size. It’s easy for the original customers directly upgraded to ASDA - B2 series.

2) Panel control operation, can be directly set on the drive

3) Screw type wiring board design, does not need additional plug connector, saving time and saves cost.

4) Built-in retrogradation resistance (more than 400 w), do not take a wiring space.

Product Tags:

ac motor

electric servo motor

Three phase ac motors 40mm Series Mini Servo Motor 220V 50W 0.16N.M 3000rpm High Speed Ac Servo Motor Images
